Population-genetics modules (TreeMix and PLINK)

Edit

Goal

Add missing building blocks for population-structure and population-history analysis to nf-core/modules: a TreeMix module, conversion of PLINK allele frequencies into TreeMix input, and a PLINK per-population allele-frequency module. Each should be merged, or at least in review, by the end of the hackathon, with nf-test coverage and a complete meta.yml.

Description

nf-core/modules already covers several steps of genotype-based population-structure workflows, including PLINK and PLINK 2 modules for filtering, extraction, LD pruning and PCA (plink/extract, plink/indep, plink2/filter, plink2/pca, among others), as well as an admixture module.

What is currently missing are the components needed to extend these analyses toward population relationships and migration history with TreeMix.

These modules are intended as reusable building blocks for population-genetics workflows using SNP-array and PLINK-compatible data. They also form part of the proposed nf-core/popstructure workflow (proposal #170), which overlaps in scope with the existing consepopgen pipeline.

The modules we plan to build:

• PLINK allele frequencies: Calculates per-population allele frequencies from PLINK data (--freq with population assignments).
• TreeMix input conversion: Converts per-population allele-frequency output into the format required by TreeMix.
• TreeMix: Fits a population tree with user-defined migration edges, root population, seed and block size.

Two design points we want to get right from the start:

• Scientific choices stay explicit. The number of migration edges, root population, block size and random seed are exposed as inputs rather than hidden defaults, so analytical choices are recorded and reproducible.
• Species independence. Non-standard chromosome sets (for example --chr-set) and population labels should work across organisms rather than assuming human chromosome conventions.

Tasks

Good project for anyone who wants to learn how nf-core modules are written, and for population geneticists who know these tools and want to see them wrapped properly.

Specific tasks:

• Open a module request issue for each missing module and link it to the project
• Write the PLINK per-population allele-frequency module
• Write the TreeMix input-conversion module
• Write the TreeMix module, including outputs for the tree, edges, residuals and likelihood files
• Add nf-tests with a small test dataset and snapshots that are stable across runs; TreeMix is stochastic, so a fixed seed will be used for testing
• Fill in meta.yml, environment.yml and topic channels for versions, then run nf-core modules lint
• Contribute a small population-genetics test dataset to nf-core/test-datasets if a suitable one does not already exist

Stretch goals

• Add PLINK genetic-distance and runs-of-homozygosity modules
• Sketch a reusable population-structure subworkflow chaining the new modules, as a first step toward the proposed nf-core/popstructure pipeline

If you have data or a workflow that uses TreeMix, ADMIXTURE or PLINK, bring it. Real use cases will help us decide which parameters need to be exposed.

Making PRs

Module PRs go against the master branch of nf-core/modules.

Test data goes to nf-core/test-datasets.

Post in the project Slack channel to get paired with a reviewer, or find one of the leads at the table.
